Profile Aluminium Standard 4040 (Cut Length)

19.45 / m

Profile Aluminium Standard 4040

This is a cut-to length product

Product Price
Please note:
An additional cutting cost of €2.90 an item is added in the basket.
PAS4040P , , , ,

Description

Extruded aluminium profiles are ideal for constructing equipment for machine frames, guarding, conveyors to cabinets, benches and bespoke one off designs. Our profile is designed to improve the structural integrity of any frame being built. Our connection method is superior to others in that we use connectors to join the profile lengths together, meaning we don’t need to redrill the connecting bar if changes are required. All of Quantum 3’s extruded aluminium profiles have a 14mm slot. This range of profile has an M8 slot and is open on all sides.

This is a cut-to length product, for full 6m length, please click here

To download a CAD file for PAS 4040 click here

To download a PDF drawing of PAS 4040 click here

Specification

Materials:

Aluminium Alloy 6063

Finish:

Clear Anodized

Thread Size:

M8

Area Moment of Inertia Ix (in cm4):

10

Area Moment of Inertia Iy (in cm4):

10

Additional information

Weight 1.68 kg
Options

,
